    High Definition Indoor Full Color P1.667 200x150mm Pitch Panel LED Display Screen

    Ask Lasest Price
    Brand Name : Yuto
    Model Number : P1.667
    Certification : CE ROHS FCC
    Payment Terms : T/T, Western Union, MoneyGram, L/C
    Delivery Time : 25-30 working days after payment
    Price : Negotiation
    Supply Ability : 1500 square meter per month
    • Product Details
    • Company Profile

    High Definition Indoor Full Color P1.667 200x150mm Pitch Panel LED Display Screen


    High Definition Indoor Full Color P1.667 200x150mm Pitch Panel LED Display Screen



    Product Description

    P1.667/1.923 Indoor Small Pixel Pitch rental LED Display screen
    1.Parameter:
    1.LED Module
    Dot Pitch(mm)1.667mmSize(W×H)200*150mm
    Pixel Point(Dot/ m2)359856 dots/m2Resolution(W×H)120 * 90 dots
    2.LED Lamp: HuaTian
    3. Rental Cabinet or Wall Frame
    Module sizes200*150mm
    Cabinet Size(W×H)400mm * 300mm
    Module Weight(g/pcs)About 600g/pcs
    4.Led Display Specification
    ITMESPECIFICATION
    LED DisplayBest View distance:1.667~15m
    Viewing angle-Horizontal :160 degree;
    Viewing angle-Vertical :110 degree
    Environment Temp: -40ºC ~ +85ºC
    Working Temp: -20ºC ~ +50ºC
    Operating Humidity Range:≤10~95%
    Power SupplyOperating Voltage: 220V±5%
    Average Power: 400W/m2
    Max Power: 900W/m2
    Control SystemLinsn/ Nova/ HuIdo
    Main Technical ParameterFull white brightness:≥800nits
    Driving IC:MBI5124 Led Driver
    Scan mode:1/30 scan
    Frame frequency:≥60 HZ/s
    Refresh rate:≥960 HZ/s
    Grey scale levels/Color processing:65536levels, Process 16.7M colors
    Brightness adjustment mode: 100 levels available
    MTBF:≥10,000 hours
    Life-span:100,000 hours
    Flatness:neighbor pixel≤0.5mm;module joint gap<1mm ;


    2. Product Features:
    1) High brightness(>800cd/㎡ ), adjustable.
    2) Clear vivid image quality.
    3) Good Raw Materials: Opto/ Epistar/ Silan/ Huacan/ Sanan led chip, Nationstar led lamp, MBI IC, Chenglian/ Meanwel Power Supply, Meanwel/ ADDA fan, Beijing/ Korean glue.
    4) Installation is simple by fast lock.
    5) High stability and long span: Aging test at least 24 hours before shipment, 100, 000 hours life span.
    6) Cabinet: Diecasting aluminum rental cabinets 640*640mm or standard iron waterproof 960*960 cabinets.
    7) Package: Flight case, wooden box package & carton box and so on.
    8) Guarantee:2 years.


    3. Application Case:
    Our full color LED display are widely used in commercial advertising, entertainment industry, financial industry,communications, power sector, traffic, stadium, plaza, school, airport, bus station etc. for advertising and displaying messages.



    4. Our services:
    1) Your inquiry will be replied within 24 hours!
    2) 2 years for warranty, service time: 24 hours*7 days.
    3) Aging test at least 24 hours before shipment.
    4) Factory and product inspection accepted.


    5. Trade Terms:
    1) Packing: Anti-shaking wooden cabinet /Air flight case/carton.
    2) Shipping port: Shenzhen. China.
    3) Shipping freights are quoted according to your requests.
    4) Delivery time:5-15 working days.
