    500x1000mm Cabinet Indoor Full Color LED Display 65536 dot/㎡ Density

    Ask Lasest Price
    Brand Name : Yuto
    Model Number : P3.91
    Certification : CE ROHS FCC
    Payment Terms : T/T, Western Union, MoneyGram, L/C
    Delivery Time : 15-20 working days after payment
    Price : Negotiation
    Supply Ability : 2000 square meter per month
    • Product Details
    • Company Profile

    500x1000mm Cabinet Indoor Full Color LED Display 65536 dot/㎡ Density


    Rental 500x1000mm Cabinet P3.91 Indoor Die-casting Aluminum Full Color LED Display


    Product Description

    (1) LED unit module board &IC
    The quality of LED module directly affects displaying effect.
    LED module consists of LED lamps, driven IC and PCB circuit board.
    IC: MBI 5124
    LED encapsulation : Kinglight,Nationstar


    (2) Frame or Cabinet
    Aluminum Frame or steel cabinet is used to hold up module boards/panels.

    (3) Power supply
    Usually use switch power supply, the brand can be : G-Energy ; C.L. ; Meanwell!
    Input 220V / 110V and Output 5V DC


    (4) Control Card
    Novastar High refresh Control Card

    (5) Cables

    Data cable, transmitting cable and power cable
    Data cable is used to connect control card with LED modules.
    Transmitting cable is used to connect control card with computer.
    Power cable is used to connect power supply with LED module and control card.


    Specifications:


    Modle No.P3.91(Indoor)S3.91(Indoor)
    Pixel Pitch3.91mm
    Pixel Configuration1R1G1B
    LED EncapsulationSMD2020
    Pixel Density65536dots/m2
    Brightness900--1200nit
    Color Temperature6500-9500K
    Drive Mode1/16
    Cabinet Size(W*H*D)500*1000*(69±5)mm500*500*(69±5)mm
    Cabinet Resolution256*128128*128
    Cabinet Weight(11.5±0.5)kg(9.0±0.5)kg
    Max Pqwer Consumption≤560w/m2
    Average Power Consumption≤280w/m2
    Best Viewing AngleH:140° V:120°
    Refresh Rate≥1000Hz
    Grey Scale14-16bit
    Best Viewing Distance2--14m
    Protection LevelIP30
    Cabinet MaterialDie-casting Aluminum
    Operation Voltage110-220v (47-63Hz)/200v-240v(47-63Hz)
    Working Humidity10%--60%
    Working Temperature-20--+55ºC


    P3.91/P4.81 Outdoor HD Rental LED Display Screen (500*500mm)

    P3.91/P4.81 Outdoor HD Rental LED Display Screen (500*500mm)


    FAQ


    1: What is the warranty of your led display?

    A: We offer 2 years warranty.and more than 100000 hours screen life span


    2: What is your payment term?How long it takes to delivery?

    A: We usually accapt the T/T or paypal.both of them will at least 30% deposit in advance,and the rest of 70% will paid before delivery.The lead time is usually 20 day


    3: How can you ensure the led display product quality?

    A: Before shippment,all the screens have aging test.and then we also have waterproof test and shake test,ensure products can transportation safety and normal use.


    4: What is your pre-sale and post-sale service?

    A: For pre-sale service,we have professional sales team and technical team,who are willing to answer your question within 24 hours.


    For post-sale service,we will instruct you how toinstallation,how to use,how to change the broken moudles,and we can also send the technicals to your country,in general,our led display will not have a big problem,you can rest assured to buy.
