HD Advertising Rental LED Display Screen 111111 dot/㎡ Density 192x192mm Module Size

Shenzhen Dehao Optoelectronic Technology Co.Ltd
Contact Now
    Buy cheap HD Advertising Rental LED Display Screen 111111 dot/㎡ Density 192x192mm Module Size from wholesalers

    Buy cheap HD Advertising Rental LED Display Screen 111111 dot/㎡ Density 192x192mm Module Size from wholesalers
    • Buy cheap HD Advertising Rental LED Display Screen 111111 dot/㎡ Density 192x192mm Module Size from wholesalers

    HD Advertising Rental LED Display Screen 111111 dot/㎡ Density 192x192mm Module Size

    Ask Lasest Price
    Brand Name : Yuto
    Model Number : P3
    Certification : CE ROHS FCC
    Payment Terms : T/T, Western Union, MoneyGram, L/C
    Delivery Time : 15-20 working days after payment
    Price : Negotiation
    Supply Ability : 3000 square meter per month
    • Product Details
    • Company Profile

    HD Advertising Rental LED Display Screen 111111 dot/㎡ Density 192x192mm Module Size


    HD Advertising Full Color P3 Indoor Rental LED Board Display Screen


    Product Description

    Technical Parameter

    LED Light Parameter
    LEDLED brandLED typewave Length(nm)Average Brightness
    (mcd)
    Test Condition
    Red(R)SananSMD
    2121 (Black)
    620-625nm130-190mcd25ºC,20mA
    Green(G)Huacan516-530nm200-300mcd25ºC,10mA
    Blue(B)Huacan465-475nm23-40mcd25ºC,5mA

    Pixel/Module
    NoItemParameter
    1Pixel Pitch3mm
    2Pixel Configuration1R1G1B / R:G:B=3:6:1
    3LED LampFull color
    4Density111111dot/m2
    5Module Size192*192mm
    6Module Pixel64*64=4096dot
    7Module Thickness15mm
    8Module Weight154g
    9Module Power≤13W
    10Drive VoltageDC5V
    11Module Electric Current1.5-2.5A
    12Port TypeHUB-3.0D/B

    Screen Parameters
    Module
    Technical ItemsUnitValues
    Pixel pitchmm3
    LED LampSMDSMD2121
    Module sizemmL192*H192*T13
    Pixels density/m2111111
    Pixel resolutiondots64x64=4096
    Pixel configurationR/G/B1,1,1
    Drive typeConstant current
    Scan mode1/32 scan
    Port typeHUB75
    Module weightKG0.35
    Module working voltage220VAC±15%
    Module Max.ConsumptionW 20
    Display screen
    Viewing angleDeg.120o
    Best viewing distancem3-45
    Drive device2016/5020/20167
    Module number per squire meterPCS27.13
    Maximum power ConsumptionW/ M21100
    Frame FrequencyHZ≥60
    Refresh frequencyHZ≥2000
    Brightness of white balanceCD/m2≥1200
    Working environment temperature0C-10~60
    Working environment humidityRH10%~70%
    Display working voltageVACAC46~54HZ,220V±15%/110V±15%
    Colour temperature9500K-11500K
    Gray degree≥16.7M
    Input signalRF S-Video RGB etc
    Control systemPCTV non-linearity card,DVI display card,Linsn control system
    Mean free error timeHours>5000
    LifetimeHours100000
    Lamp failure frequency<0.0001
    Anti-jammingIEC801
    SafetyGB4793
    Resist the electricityNo breakdown by 1500V last 1min
    WeightKG/ M240(standard steel box)
    IP GradeThe back IP40,The front IP50
    Steel box sizemmL576 x W576 x 80

    Product Advantages:
    High refresh rate: With NOVA control system,no scanning line when photographed.
    High gray level: 256 RGB each, display 16.7M colors, vivid and perfect video effect.
    High resolution: The most apparent features of the new generation of LED display.
    Good color uniformity:With brand Lamp Nationstar and high refresh MBI5124 IC.
    High Brightness: 6000-8000cd/m2, brightness automatically adjusted.
    High Quality: CE, RoHs, FCC, UL, IP65, ISO9001 passed + 96 Hours serious testing time.
    Long life span: over100,000hours, warranty at least 2 years.
    You need = We design: Provide Personal- Customized led offer.
    Price Advantage:

    We have the best competitive price at the market, also have the same even better quality
    Quality advantage:

    From material to finished product, from design to produce, we control all steps,that's the guarantee of the quality and reliability
    Service advantage:

    Better service at same situation, better cooperation at same service.
    Performance Advantage:

    Best equality, high consistency, big viewing angle, can repair each led lamps
    Die Casting Aluminum Cabinet
    Application Range:indoor or outdoor rental business, support hanging
    Structure:with back door,cooling fan,small position guiding pillar,side locks,and hanging design,precision die-casting cabinet suit for fix installation and rental projects, light weighted, fast assemble and easy maintenance,most use in rental business.
